Inverter Chillers

Gem Orion proudly introduces inverter or VFD driven Precision chiller, that delivers a control precision of as low as ±0.1°C combined with smart power saving, first of its kind in India. With this, Indian product is now at par with any imported product and available at affordable price.

Inverter chillers, equipped with advanced variable-speed technology, making them a sustainable and cost-effective choice for temperature control in various applications.

Starting Currents of Other Starters VS VFD
Inverter Inner Image

Get a Quote Contact Us Download Catalogue

Features

Inverter chiller working with renewable energy sources for sustainable cooling - Gem Orion Machinery Pvt Ltd Precise control of temperature (as low as ±0.1°C from set point).
Benefits infographic highlighting the advantages of inverter chillers - Gem Orion Machinery Pvt Ltd Environment friendly, Energy efficient refrigerant - R410A (No phase out as per Montreal Protocol).
Gemorion Machinery Pvt Ltd staff providing product training on inverter chillers - Gem Orion Machinery Pvt Ltd Larger Operating range (from 10 to 30°C).
Chiller plant layout featuring multiple inverter chillers in operation - Gem Orion Machinery Pvt Ltd Wider ambient temperature (from 10 to 50°C).
Installation process of an inverter chiller in an industrial environment - Gem Orion Machinery Pvt Ltd Smart operation to ensure lowest power consumption.
Inverter chiller's innovative design for reduced noise and vibration - Gem Orion Machinery Pvt Ltd Inverter or VFD driven Hermetically Sealed Scroll compressors.
Features brochure for Gem Orion Machinery's inverter chillers - Gem Orion Machinery Pvt Ltd In-built water tank made of SS304 material amply sized.
Gemorion Machinery Pvt Ltd factory showcasing inverter chiller production line - Gem Orion Machinery Pvt Ltd In-built high pressure pumps made of SS304 Impeller & SS body.
Inverter chiller specifications including cooling load capacity and power usage - Gem Orion Machinery Pvt Ltd Pumps can operate at as high as 6 bar / 60 m head. Optionally VFD mounted pump at additional cost.
Inverter chiller with advanced insulation for improved energy efficiency - Gem Orion Machinery Pvt Ltd Brazed plate heat exchangers with SS316 plates (higher thickness for longer durability).
Eco-friendly refrigerant used in our inverter chillers - Gem Orion Machinery Pvt Ltd Inverter Driven IP rated Fan motors to ensure uniform performance across seasons.
High-performance inverter chiller for large industrial applications - Gem Orion Machinery Pvt Ltd Chillers built on Casters for ease of mobility.
Energy consumption analysis of inverter chillers displayed on a report - Gem Orion Machinery Pvt Ltd Visible water level from front.
Inverter chiller installed in a data center for cooling sensitive equipment - Gem Orion Machinery Pvt Ltd Pressure gauges to indicate refrigerant pressure & water pressure.
Inverter chiller maintenance technician performing routine checks on a unit - Gem Orion Machinery Pvt Ltd Condensers to withstand very high operating pressures.
Customer feedback on the performance of our inverter chillers - Gem Orion Machinery Pvt Ltd Dust filter mesh to ensure less interruption to operation & ease of maintenance.
Graph comparing energy savings of inverter chillers versus traditional systems - Gem Orion Machinery Pvt Ltd Remote On-off as a standard feature.
Portable inverter chiller model designed for flexible applications - Gem Orion Machinery Pvt Ltd Potential free contacts for chiller status as standard feature.
Infographic detailing the components of an inverter chiller - Gem Orion Machinery Pvt Ltd Can connect 12 modules in parallel.
Gemorion Machinery Pvt Ltd engineers conducting a product demonstration of inverter chillers RS485 connectivity.
ITEM Units GKE 2200A-V GKE 3750A-V GKE 5500A-V GKE 7500A-V GKE 11000A-V GKE 15000A-V GKE 18000A-V GKE 22000A-V GKE 30000A-V
Cooling Capacity *1 kW 8.7 12 20 25 35 45 57 70 90
External Dimensions (H x D x w) mm 1485x905x805 1684x905x805 1825x988x885 1646x800x1340 2020x919x1600 2124x924x1603 2320x1180x2200
Unit Mass (dry weight)(when tank empty) kg Approx. 200 Approx. 240 Approx. 260 Approx. 320 Approx. 475 Approx. 480 Approx. 560 Approx. 1050 Approx. 1420
Operable Ambient Temp. Range °C 5 to 50
Operable Liquid Temp. Range °C 10 to 30
Control Precision *4 ±0.5°C (±0.1°C Possible @ Stable Load Condition)
Operating Water Pressure MPa 0.25 ~ 0.50 0.25 ~ 0.50 0.35 ~ 0.55 0.35 ~ 0.55 0.5 ~ 0.7
Operating Flow Rate L/min 30 ~ 70 30 ~ 70 24 ~ 110 160 ~ 250 180 ~ 350
Inlet and Outlet Port Size BSP1" BSP1 1/4" BSP2"
Power Source *2 V(Hz) 3 Phase.400V ± 5% (50Hz)
Power Connected *1 kW 3.8 5.6 8 9.5 16.4 19.7 25.2 30.64 37.9
Maximum Current *1 A 6.5 9.3 13.2 15.5 28.5 34.0 42.02 53.9 64.8
Power Capacity *3 kVA 4.5 6.4 9.1 10.7 19.8 20.80 29.11 37.35 44.9
Compressor Inverter Driven Scroll type
Condenser Finned tube type, Forced air cooling
Operation Control Method Inverter Drive
Evaporator Construction / Material Plate type/SUS316(with copper brazing)
Discharge Pump Construction / Material Multistage centrifugal pump(SS Body, SS Impeller, Cl end connection)
water Tank Capacity L Approx. 44 Approx. 95 Approx. 115 Approx. 140 Approx. 220 Approx. 320
Refrigerant R - 410A

*1. Cold water temperature 25°C, Room temperature 38°C.
   Cooling capacity is at least 95% of listed figures.

* 2. Voltage imbalance should be within ±2%.

* 3. The figure noted is when operating at the highest capacity in the normal operating range.

* 4. Not in scope when compressor is off and when load is less than or equal to 30% of rated capacity.

Model Variants:

GKEXXXXX A - *

V - Cold Tank

H - Hot Tank

W - Without Tank
